Product Description:
Figure 8 Fiber Optic Cable
Fiber Optic Communication Cable for High-speed Data Transmission
The Figure 8 Fiber Optic Cable is a specialized type of aerial
fiber optic cable designed for high-speed data transmission. With
its unique figure 8 shape and advanced features, this cable is
ideal for a variety of applications in telecommunication, internet,
and cable television industries.Featuring a Bending Radius of 20D , this cable is able to withstand tight bends without compromising
its performance. This makes it highly suitable for installations in
confined spaces such as ducts or conduits.
The UV PE Jacket of this cable provides excellent protection against environmental
factors such as sunlight, moisture, and extreme temperatures,
ensuring long-term durability and reliability. This jacket also
makes the cable suitable for both indoor and outdoor
installations.For added strength and support, the Figure 8 Fiber
Optic Cable is equipped with Stranded Steel Wire . This provides extra reinforcement and allows the cable to be
self-supporting, making it suitable for aerial installations and
reducing the need for additional support structures.The 9/125μm Fiber Diameter of this cable allows for high-speed transmission of data over long
distances, making it ideal for use in telecommunication networks.
The 7.0mm-16.0mm Outer Diameter of the cable offers a wide range of options for different
installation requirements.
Overall, the Figure 8 Fiber Optic Cable combines advanced features
and superior design to provide efficient and reliable fiber optic
communication for various industries. Its unique figure 8 shape and
high-quality components make it a top choice for high-speed data
transmission needs.
Features:
- Product Name: Figure 8 Fiber Optic Cable
- Jacket: UV PE
- Weight: 90kg/km
- Bend Radius: 20x Cable Diameter
- Fiber Diameter: 9/125μm
- Jacket Material: LSZH
Key Features:
- High-quality Fiber Optic Cable designed for reliable data
transmission
- Customized Fiber Optic Cable to meet specific project requirements
- UV PE jacket provides protection against outdoor elements and harsh
environments
- Lightweight design with a weight of 90kg/km for easy installation
and maintenance
- Bend radius of 20x cable diameter allows for flexible and
convenient installation
- Fiber diameter of 9/125μm ensures high-speed data transmission
- LSZH jacket material for enhanced safety and low smoke emission in
case of fire
Technical Parameters:
| Product Name | Figure 8 Fiber Optic Cable |
|---|
| Product Type | Aerial Figure 8 self-supporting optical cable |
|---|
| Fiber Cores | 4-144 cores |
|---|
| Cladding Diameter | 125.0±0.1 μm |
|---|
| Fiber Diameter | 9/125 μm |
|---|
| Bend Radius | 20x Cable Diameter |
|---|
| Weight | 90 kg/km |
|---|
| Armored Material | Aluminum Tape or Steel Tape |
|---|
| Jacket | UV PE |
|---|
| Cable Use | Outdoor |
|---|
| Bending Radius | 20D |
|---|
| Water Blocking System | Filling Compound |
|---|
Customization:
Customized Services for Figure 8 Fiber Optic Cable - JQ
GYTC8S/GYXTC8S
Welcome to JQ, your one-stop solution for high-quality and reliable
fiber optic products. We are proud to offer our Figure 8
self-supporting optical cable, a perfect choice for outdoor
installations. With our customized services, you can tailor this
product to meet your specific needs and requirements.
Fiber Optic Patch Cables
In addition to our Figure 8 Fiber Optic Cable, we also offer a
range of fiber optic patch cables that are suitable for indoor and
outdoor use. These cables are customizable and can be tailored to
meet your specific needs and requirements.
you can be assured of top-quality products and customized services
for all your fiber optic needs. Contact us today to learn more
about our Figure 8 Fiber Optic Cable and other products.
Packing and Shipping:
FAQ:
- Q: What is the brand name of Figure 8 Fiber Optic Cable?
- A: The brand name is JQ.
- Q: What are the model numbers for this product?
- A: The model numbers are GYTC8S and GYXTC8S.mn
- Q: Where is this product manufactured?
- A: It is manufactured in Guangzhou, China.
- Q: What is the design of this cable?
- A: It has a figure 8 design, hence the name "Figure 8 Fiber Optic
Cable."
- Q: What is the primary use of this product?
- A: This product is used for high-speed data transmission through
optical fibers.
