ADSS cable is a type of fiber optic cable that is strong enough to support
itself between structures without containing conductive metal
elements. Both single mode and multimode fibers can be arranged in
ADSS cables with a maximum of 288 fibers. ADSS fiber optic cable is
designed for outside plant aerial and duct applications in local
and campus network loop architectures from pole-to-building to
town-to-town installations. The cabling system that includes
cables, suspension, dead-end, and termination enclosures offers a
comprehensive transmission circuit infrastructure with
high-reliability performance. Jiqian's ADSS fiber cable has the characteristics of full dielectric, no metal,
non-conductivity, small cable diameter, high tensile force, low
linear expansion coefficient, and wide temperature adaptation.
Fiber parameter
| | G.652 | G.655 | 50/125μm | 62.5/125μm |
| @850nm | | | ≤3.0 dB/km | ≤3.0 dB/km |
| @1300nm | | | ≤1.0 dB/km | ≤1.0 dB/km |
| @1310nm | ≤0.00 dB/km | ≤0.00 dB/km | | |
| @1550nm | ≤0.00 dB/km | ≤0.00 dB/km | | |
| Bandwidth(Class A) | @850nm | | | ≥500 MHz·km | ≥200 MHz·km |
| @1300nm | | | ≥500 MHz·km | ≥500 MHz·km |
| Numerical aperture | | | 0.200±0.015NA | 0.275±0.015NA |
| Cable Cutoff Wavelength | ≤1260nm | ≤1480nm | | |
Fiber color code:
| No. | 1 | 2 | 3 | 4 | 5 | 6 |
| Colour | Blue | Orange | Green | Brown | Gray | White |
| No. | 7 | 8 | 9 | 10 | 11 | 12 |
| Colour | Red | Black | Yellow | Yellow | Pink | Aqua |
Packing: plywood drum 2/3/4/5 one drum or as your requirement
Delivery:By sea/road/train
Company profile:
Guangzhou jiqian fiber optic cable co.,ltd is a high-tech company
group engaged in researching, manufacturing, selling
communication products with our import and export rights. Our
corporation is a professional manufacturer of fiber optic cable for
12 years, with ISO9001, FCC, ROHS and CE certificates. We OEM or
design any structure of fiber optic cable for you. The main
products of our company are: optical fiber cables/FTTH Drop Cable.
All of the products are widely used in telecom, railway and other
communication products related department, exported to many
countries and districts such as North/South America, Europe,
Mideast and Southeast Asia.Africa
