Specification:
| item | value |
| Model Number | ADSS |
| Type | Outdoor Fiber Optic Cable |
| Place of Origin | Guangdong,China |
| Brand Name | jiqian |
| Cable type | Outdoor All dielectric self-supporting aerial cable ADSS |
| Cable Structure | FRP+aramid yarn+outher sheath |
| Number of Conductors | ≥ 10 |
| Fiber count | 2-144 Cores |
| Fiber material | silicon dioxide |
| Fiber Type | G652D Single mode or as your request |
| Fiber color | Blue, Orange, Green, Brown,etc |
| Central strength member | FRP |
| Loose tube | Jelly filled |
| Loose Tube | Stranded Loose Tube |
| Loose tube Material | PBT |
| Water Blocking | Water Swell able Material |
| Jacket Sheath | PE |
| Color | Black or as your need |
| Package | Plywood Reel/customized |
| Installation | Self-supporting aerial |
| Span | 150 meters |
| operating temperature | -40 to +70 |
| Certification | CE/ROHS/ISO9001 /ANATEL |
Optical Characteristics:
| G.655 | 50/125μm | 62.5/125μm | |
| G.652 | |
| Attenuation | '@850nm | | | ≤3.0 dB/km |
| (+20℃) | '@1300nm | | | ≤1.0 dB/km |
| '@1310nm | ≤0.34 dB/km | ≤0.40 dB/km | |
| '@1550nm | ≤0.21 dB/km | ≤0.23 dB/km | |
| '@850nm | | | ≥500 MHz·km |
| '@1300nm | | | ≥1000 MHz·km |
| Numerical Aperture | | | 0.200±0.015NA |
Company Profile:
Guangzhou Jiqian Fiber Optic Cable Co.Ltd. is located in 2nd
Floor,Building B3,Building 3 No.43 Lixin 9th Road,Xintang
Town,Zengcheng District,Guangzhou city,Guangdong province,China.It
is a large-scale high-tech specialized joint-stock enterprise that
integrates scientific research, development,production, and sales.
It specializes in producing various types and specifications of
optical cables with 2-288 cores. The company adheres to the
corporate spirit of "integrity, speed, flexibility, efficiency, and
innovation", and strives for perfection, appreciation for
customers, and paving the way for success, Adhere to the standard
that "customer satisfaction is the most important measure of our
performance". We promise to work together with you with
high-quality products, discounted prices,and first-class services
to create a brilliant career.
We sincerely welcome customers all over the world to visit our
factory and build long term relationship with each other.
WHY CHOOSE US:
Certification:
FAQ:
1. who are we?
We are based in Guangdong, China, start from 2017,sell to
Africa(33.00%),South America(17.00%),Western Europe(17.00%),Mid
East(17.00%),Southeast Asia(9.00%),South Asia(7.00%). There are
total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Fiber Optic Cable, FTTH Drop Cable, Communication Cables,
Outdoor/Indoor Fiber Cable
4. what services can we provide?
Accepted Delivery Terms: FOB,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal,Western
Union,Cash;
Language Spoken:English,Chinese
5.MOQ: what is your minimum quantity?
-MOQ : 1KM
6.Can I get a sample?
-Yes, we provide FREE sample and you just need to pay for express
freight.
7.Accept OEM or ODM?
-Yes,we're manufacturer. And we have our own Engineering
Department. You just need to tell us your requirements.
8.What is your delivery time?
-The general delivery time is 3-7 days after order confirmed. It
depends on the order quantity.
