8 12 24 Core Monomodo Fibra Optica Central Tube Steel Tape Armor
Fiber Optic Cable
Product Details
The fibers,250μm,are positioned in a loose tube which made of a
high modulus plastic.
The tube are filled with a water-resistant filling compound.
The loose tube is wrapped with a layer of PSP
longitudinally.Water-blocking material is applied between PSP and
the loose tube so that that can keep the cable compact and
watertight.
Two parallel steel wires are placed at the two sides of the steel
tape.
Finally,the cable is completed with a polyethylene(PE) sheath.
Characteristics
1.Good mechanical and temperature performance
2.High strength loose tube that hydrolysis resistant
3.Special tube filling compound ensure a critical protection of
fiber itself
4.Crush resistance and flexibility
5.PSP enhanceing moisture-proof
6.Two parallel steel wires ensure tensile strength
7.Small diameter,light weight and friendly installation
8.Long delivery length
Features:
Fiber:
2-24 fibers G652D/G657A1/G657A2
Unit- loose tube with gel filled
Armor:
Corrugated steel tape armored
Strength Member:
Embedded two parallel steel wires
Outer jacket:
Black UV-and moisture-resistant polyethylene (PE)
Applications
Installed:aerial
Optical Parameters:
·Technical Parameters
| Fiber count | Structure | Fibers per tube | Loose tube diameter (mm) | CSM diameter/pad diameter (mm) | Nominal Thickness of outer jacket (mm) | Cable diameter/ Height (mm) | Cable weight (kg/km) |
| 2 | 1 | 2 | 1.7±0.1 | 1.0/1.0 | 1.6 | 8.0±0.2 | 57 |
| 4 | 1 | 4 | 1.85±0.1 | 1.0/1.0 | 1.6 | 8.0±0.2 | 58 |
| 6 | 1 | 6 | 1.9±0.1 | 1.0/1.0 | 1.6 | 8.0±0.2 | 58 |
| 8 | 1 | 8 | 2.0±0.1 | 1.0/1.0 | 1.6 | 8.0±0.2 | 60 |
| 12 | 1 | 12 | 2.2±0.1 | 1.0/1.0 | 1.6 | 8.0±0.2 | 60 |
There are twelve fiber color code.They are A grade fiber.
All products will have been strictly quality checked in house
before packing.
All products will be well packed before shipment.
We are the factory, having quality control.
We privide you factory price.You can save costs, having good
quality.
Package: Wooden reel, 1000m/reel, 2000m/reel, 3000m/reel, customer's
requirements are also welcomed
We go to exhibitions. We have rich foreign trade experience, you
can save purchasing time.
Don't hesitate to contact me. Whatsapp:+86 18122383351
FQA
1,Q:Are you a factory or trade company?
A:We are a factory
2,Q:What is the MOQ?
A:The MOQ of Fiber Optic cable is 1km.
3.Q:Which brand of fiber do you use?
A:YOFC,Fiberhome,etc
4,Q:Can you accept small order?
A:Yes, small order is available .We support new project of our
customers as we know business is always from small order.
5,Q:What’s delivery time?
A:The general delivery time is 5-7 days after order confirmed. It
depends on the order quantity.
6.Can you supply customized products and logo?
A:Yes. We supply OEM service.
7.What’s your payment terms?
A: We accept T/T,L/C,Western Union, 30% Deposit and 70% before
shipment.
