PE jacket Armored Duct Aerial Carble , 12 Core Fiber Optic Cable

Ask Lasest Price
Brand Name :	Jiqian
Model Number :	GYTA
Certification :	CE/ISO9001
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	60000KM/month
Delivery Time :	3-5 days, it depends on your quantity

Add to Cart

Product Details
Company Profile

PE jacket Armored Duct Aerial Carble , 12 Core Fiber Optic Cable

Duct Aerial Armored Single Mode Gyta 12 24 36 48 72 Core Fiber Optic Cable

Data Sheet

Cable Type	Fiber Count	Tubes	Fillers	Cable Diameter mm	Cable Weight kg/km	Tensile Strength	Crush Resistance	Bending Radius
						Long/Short Term	Long/Short Term	Static/ Dynamic
						N	N/100mm	mm
GYTA	2~6	1	4	10.2	116	600/1500	300/1000	10D/20D
GYTA	8~12	2	3	10.2	116	600/1500	300/1000	10D/20D
GYTA-14~18	14~18	3	2	10.2	116	600/1500	300/1000	10D/20D
GYTA-20~24	20~24	4	1	10.2	116	600/1500	300/1000	10D/20D
GYTA-26~30	26~30	5	0	10.2	116	600/1500	300/1000	10D/20D
GYTA-32~36	32~36	6	0	10.6	129	1000/3000	300/1000	10D/20D
GYTA-38~48	38~48	4	1	11.2	141	1000/3000	300/1000	10D/20D
GYTA-50~60	50~60	5	0	11.2	141	1000/3000	300/1000	10D/20D
GYTA-62~72	62~72	6	0	12	159	1000/3000	300/1000	10D/20D
GYTA-74~84	74~84	7	1	13.6	209	1000/3000	300/1000	10D/20D
GYTA-86~96	86~96	8	0	13.6	209	1000/3000	300/1000	10D/20D
GYTA-98~108	98~108	9	1	15.4	232	1000/3000	300/1000	10D/20D
GYTA-110~120	110~120	10	0	15.4	232	1000/3000	300/1000	10D/20D
GYTA-122~132	122~132	11	1	17.2	280	1000/3000	300/1000	10D/20D
GYTA-134~144	134~144	12	0	17.2	280	1000/3000	300/1000	10D/20D

PE jacket Armored Duct Aerial Carble , 12 Core Fiber Optic Cable

GYTA is designed to provide high fiber counts with the flexibility and versatility required for today's most demanding installations, including duct and underground conduit.

PE jacket Armored Duct Aerial Carble , 12 Core Fiber Optic Cable

Packaging Details
1.Wooden reel, 1000m/reel, 2000m/reel, 3000m/reel, customer's requirements are also welcomed;
2.Inner packed in fumigated wooden drum, and outer covered by polyethelene sheet, then sealed by strong wooden battens.

Delivery
 For large orders: by sea (LCL or FCL)
 For small orders: by sea (LCL), by air or by courier services(DHL ,UPS,TNT.....)
