Overhead Outdoor Single Mode Fiber Optic Cable Steel Wire Strand 24 48 288 Core Figure 8

Ask Lasest Price
Brand Name :	JQ/OEM
Model Number :	GYTC8S
Certification :	CE/ISO9001
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	80000kilometers per month
Delivery Time :	2-4 days

Add to Cart

Product Details
Company Profile

Overhead Outdoor Single Mode Fiber Optic Cable Steel Wire Strand 24 48 288 Core Figure 8

Outdoor aerial self supporting 24core 48core g652d g657a fiber optical figure8 cable gytc8s

Features
Loose tube gel-filled construction for superior fiber protection.
UV and moisture-resistant design
Self-supporting Figure 8 design.
Applications
Backbones and Access.
Installed aerially.

Optical Charateristics
Fiber TypeG.652G.65550/125^m62.5/125^m
Attenuation
(+20X)
850 nm≤3.0 dB/km≤3.2 dB/km
1300 nm≤1.0 dB/km≤1.2 dB/km
1310 nm≤0.36 dB/km≤0.40 dB/km
1550 nm≤0.22 dB/km≤0.23 dB/km
Bandwidth850 nm≥500 MHz-km≥200 Mhz-km
1300 nm≥1000 MHz-km≥600 Mhz-km
Numerical Aperture0.200±0.015 NA0.275±0.015 NA
Cable Cut-off Wavelength cc≤1260 nm≤1450 nm
Characteristics
Good mechanical and temperature performance
High strength loose tube that is hydrolysis resistant
Special tube filling compound ensure a critical protection of fiber
Crush resistance and flexibility
Standards and Certificate:
Fiber optical cable complies with Standard YD/T 769-2003,IEC60794-1
Certificate:CE ROHS ISO9001

Cable Structure

1.Stranded loose tube

2.Steel wire strength member

3.Core filler compound

4.Fillers

5.Phosphating or Galvanized steel wire

6.PE sheath

1.Low dispersion and attenuation
2.Proper design, precise control for fiber excess length and
distinct stranding process render the cable excellent mechanical
and environmental properties
3.Compact structure and lightness, flexible and good bend-resistant
performance
4.With small cable diameter, light cable weight, self-supporting
5.Operating Temperature : -40~+60°C

FAQ
1.Are you tradning company or manufacturer?
We are the manufacturer with 10 years' experience ,we are
specialized in research,development and production
for fiber optic cable. Our factory is in Guangzhou city,welcome to
visit us!
2.About the quality?
We will delivery before tested every fibers when finished
production.
After price confirmation, you can require for free samples to check
our quality.
3.Can you accept small order?
Yes, small order is available. We support new project of our
customers, as we know business is always from small order.
4.What is your delivery time?
Usually about 3-7days working days,it mainly depend on order
quantity.
But pls be assured that we will arrange your goods asap after your
payment .
5.Can you accept the OEM service?
Yes, we welcome the OEM service. We can print your logo on the
product. Any idea from you is available.

Product Tags:

Outdoor Single Mode Fiber Optic Cable

Overhead Single Mode Fiber Optic Cable

Figure 8 Outdoor Fiber Optic Cable

Overhead Outdoor Single Mode Fiber Optic Cable Steel Wire Strand 24 48 288 Core Figure 8
