    Outdoor Double Jacket Single Armoured Fiber Optic Cable DJSA

    Ask Lasest Price
    Brand Name : Jiqian
    Model Number : GYTC8Y53
    Certification : CE/ROSH/ISO9001
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram, MoneyGram
    Supply Ability : 100000pcs/day
    Delivery Time : 3-5 days, that depends on the quantity
    • Product Details
    • Company Profile

    Outdoor Double Jacket Single Armoured Fiber Optic Cable DJSA

    Outdoor Double Jacket Single Amoured 24 48 96 Core Fibra Optic Cable DJSA

    In the figure 8 cable, single-mode fibers are positioned in the loose tubes,

    while the loose tubes strand together around metallic central strength member into a compact and circular cable core,

    and the water-blocking materials are distributed into interstices of it.

    The cable is accompanied with the stranded wires as the supporting part are completed with a PE sheath to be a figure-8 supported.

    GYTC8Y53 is an optical cable with a jacket on the basis of GYTC8Y.


    Fiber parameter

    ItemUnitSpecification
    Fiber TypeG.652D
    Mode field diameter1310nmmm9.2±0.4
    1550nmmm10.4±0.8
    Cladding diametermm125.0±1
    Cladding non-circularity%£1.0
    Core/cladding concentricity errormm£0.5
    Coating diametermm245±5
    Coating non-Circularity%£6.0
    Coating/cladding concentricity errormm£12.0
    Cable cut-off wavelengthnm£1260
    Attenuation Coefficient1310nmdB/km£0.36
    1550nmdB/km£0.22
    Proof stress levelkpsi≥100

    Mechanical and Environmental Characteristics

    ItemUnitSpecifications
    Tension(Long Term)N2500
    Tension(Short Term)N5000
    Crush(Long Term)N/10cm300
    Crush(Short Term)N/10cm1000
    Min. Bend Radius(Dynamic)mm20D
    Min.Bend Radius(Static)mm10D
    Installation Temperature-40~+60
    Operating Temperature-40~+70
    Storage Temperature-40~+70
    Repeating bendingLoad:250N;number of cycles:30 No obvious addition attenuation, no fiber break and no cable damage.
    TorsionLoad:250N; number of cycles:10; twist angle:±90° No obvious addition attenuation, no fiber break and no cable damage.
    ImpactImpact energy:450g×1m; radius of hammer head:12.5mm; number of impact: 5 No obvious addition attenuation, no fiber break and no cable damage.

    Package & Delivery

    Wooden drum:1KM 2KM 3KM 4KM for one roll

    Shipping: By sea/by air or express delivery, it depends on the order quantity

    Factory Show

    We are a factory. Welcom to visit our factory.

    Certificate

    FAQ:

    1. Are you a manufacturer?
    Yes. We are a company integrating industry and trade. Our factory is located in Guangzhou, Guangdong Province, China.

    2.How can you guarantee quality?
    We conduct three inspections from raw materials to finished products, and then to the factory. 25-year guarantee period.

    3.What product do you sell?
    There are fiber optic cable, FTTH drop cable, communication cables, outdoor/indoor fiber cable.

    4 .What service can you provide?
    One-to-one service, fast response.
