G657A1 G652D Single Mode FTTH Indoor LSZH Drop Cable GJXH FTTH
Fiber Optic Drop Cable
FTTH fiber optic cable is Fiber to Home, which used for linking the
equipment and components in the fiber optic network. The fibers is
position between two parallel FRP / steel wire. Then it is
self-supported by diameter 1.0mm steel wire. it's completed with
black or white LSZH sheath.
Product Description
FTTH DROP CABLE
MODEL: GJXCH-4B6a1
Fiber: SM G657A1
Fiber Count: 4
Parallel Wire: 0.45mm *2
Messenger Wire: 1.0mm
Jacket Material: LSZH
Cable Length: 3Km/Drum
Simple Specification:
Insertion Loss: ≤0.30dB Return Loss: ≥50dB
Durability: ≤0.2dB
Test Wavelength: 1310/1550nm
Operation temperature: -40℃~ 85℃
product feature:
Part Number | Self-supporting Drop Cable GJXCH |
Fiber Count | 2 core (1 core, 4 core also) |
Strength Member | One self-supporting 1.0mm steel wire and Two parallel 0.45mm steel
wire |
Cable Dimension (WxH approx.) | (2.0±0.2)x(5.0±0.2)mm |
Out Jacket | LSZH |
Out Jacket color | black or white |
Application | FTTH cable (Fiber to the home), used indoor, Access network |
Packing & Delivery
FAQ:
1. Are you the real manufacturer?
Yes, we are factory in guangzhou china, welcome to visit us!
2. what is your minimum quantity?
1KM. We support new project of our customers, trial order is
available
3.Can I get a sample?
Yes, we provide FREE sample and you just need to pay for express
freight.
4.What about Payment?
L/C,T/T,Western Union and Paypal are acceptable.
5.Delivery time?
Generally 3-7 working days, also it is according to qty.
6.Can you supply customized products and logo?
Yes, we supply OEM&ODM service, pls feel free to contact.
