Hybrid Copper-Fiber Cables allow one cable to offer the advantages
of DC power and fiber, safely delivering both over long distances
to remote locations where standard power is unavailable or too
costly to install
Fiber G652D:
| Item | Unit | Specification |
| Fiber Type | G.652D |
| Mode field diameter | 1310nm | mm | 9.2±0.4 |
| 1550nm | mm | 10.4±0.8 |
| Cladding diameter | mm | 125.0±1 |
| Cladding non-circularity | % | ≤1.0 |
| Core/cladding concentricity error | mm | ≤0.5 |
| Coating diameter | mm | 245±5 |
| Coating non-Circularity | % | ≤6.0 |
| Coating/cladding concentricity error | mm | ≤12.0 |
| Cable cut-off wavelength | nm | ≤1260 |
| Attenuation Coefficient | 1310nm | dB/km | ≤0.35 |
| 1550nm | dB/km | ≤0.21 |
| Proof stress level | kpsi | ≥100 |
Technical parameter:
Company Profile:
1.Located in Guangzhou China
2.12 years experiance of producing fiber optic cable
3.Exporting fiber optic cable to all over the world
4.CE/ROSH/FCC/ISO9001 Certifications
Packing&shipping:
Our ADSS Fiber Optic Cable can be conveniently shipped to your
warehouse using a variety of transportation methods.such as bysea/road/railway or air
* For large volume and heavy goods, sea freight is a cost-effective
option.
* If you require faster delivery, we can provide air freight
* For shipments traveling between China and Europe, we offer the
efficient and reliable China Railway Express service, providin a
direct land-based route for timely delivery.
Exhibition:
FAQ:
1.Are you the real manufacturer?
Yes. We are the real manufacturer with over 12 years' history.
2.What is your fiber brand ?
YOFC/Fiberhome/Corning
3.Do you provide samples?is it free or charged?
Yes,samples are for free,just pay for freight
4.Can you accept small order?
Yes, small order is available .We support new project of our
customers as we know business is always from small order.
5.What is your cable life expectancy?
30 years for outdoor fiber optic cable
6.Which kind of certification you have ?
ISO9001,FCC,ROHS,CE
7.What is your delivery time?
Usually 5-7 working days,it depends on order quantity
8.What is your payment term
30% deposit,balance due before delivering goods
9.Can you supply customized products and logo?
-Yes. We supply OEM&ODM service. You can send us your drawing.
For more information please contact me
